VMC1160 3/4/5 Axis CNC Vertical Machining Center Machine High precision

Brand Name : HR

Model Number : VMC1160

Certification : CE

Place of Origin : China

MOQ : 1 set

Price : 26000 USD/SET

Payment Terms : T/T, L/C

Supply Ability : 100sets/month

Delivery Time : 30 working days

Packaging Details : Standard material packagingProduct Description The vmc1160 Cheap 3 axis cnc milling machine with CE certificate feed shaft is controlled by X, Y and Z three dimensions, and spindle is driven by frequency power. It could realize one-time clamping upon vari

Warranty : 1 Year

Weight : 8000kg

Dimension(l*w*h) : 3200*2800*3200mm

Condition : New

Type : Vertical

After-sales service provided : Engineers available to service machinery overseas,Overseas service center available,Online support

Voltage : 380V 50HZ,Customer's Requirement

Power(w) : 11/15kw

Machine type : China manufacturer machining center cnc vertical process center,Hard Rail Vertical

Spindle : Taiwan 10000rpm spindle,Hight speed and precision

Spindle taper : BT40

Product name : precision overseas service 3 axis cnc vertical machining center price

Control system : GSK FANUC Siemens Mitsubishi etc.

Guideway : linear guideways

Inner structure : Very steady

Worktable size : 1200*600 mm

Contact Now

Product Description







Items

Details

Unit

VMC1160

Table

Size

mm

1200×600

Travel of 3 axis(X/Y/Z)

mm

1100/600/600

Max, table load

kg

1000

T-slot

Size

mm

5-18×120

Spindle

Spindle taper



BT40

Distance from Spindle center to Colum guide

mm

650

Distance of spindle head to table

mm

130-780

Max speed

rpm

8000

Motor power

KW

11/15

Accuracy

Positioning accuracy(X/Y/Z)

mm

±0.01/±0.008/±0.008

Repeatability(X/Y/Z)

mm

±0.005

Axis motor

Power of X/Y/Z

Kw

2.5/2.5/2.5

Torque of X/Z

Nm

16/24

Feeding speed

Rapid feed of X/Y/Z

m/min

36/36/24(linear guide way)

Cutting feed of X/Y/Z

m/min

10

Weight

Kg

7800

Dimension

mm

3300*2800*2700

Power

V

3 phase 380V,


The vmc1160 Cheap 3 axis cnc milling machine with CE certificate feed shaft is controlled by X, Y and Z three dimensions, and spindle is driven by frequency power. It could realize one-time clamping upon various plates, boards, shells, cam, molds and etc. complex components, it can also complete drilling, milling, boring, expanding, reaming, tapping and etc. multiple processing; this machine is applied to produce various and middle & large batch of components, especially for machining of complex and
high-precision components.

Detailed description


VMC1160 3/4/5 Axis CNC Vertical Machining Center Machine High precision


VMC1160 3/4/5 Axis CNC Vertical Machining Center Machine High precision
